RE10 Series Thermal Printers

Specifications Type:Hand TIJ Operating System:Linux Dimension:242 X 120 X 125mm Weight:0.95 Kg CPU: Quad 1.4 GHz Interface: USB Battery:2600Mah, DC 16.8V Adapter:AC Input 100V to 240V,DC Output 16.8V / 2A Conditions :Temperature 5°C-45°C, Humidity 40%-60% Ink Type: Solvent Base/42ml, Water Base Ink Colors: Black, White, Red, Blue, Yellow, Green Features Language Support: English, Arabic, Chinese, Turkish Content: Numbers, Symbols, QRCode, BarCode, Date, Time, Counter Print Distance:2 To 5mm Print Resolution:600dpi Maximum Max Print Height:2 To 12.5mm

Memory: Store up to 3GB of templates on the printer memory Languages: English, Spanish, Portuguese, Turkish, Arabic, Farsi, French, German, Thai, Korean, Japanese, Russian, Italian, etc. any language can be customized. Print Content: Variable code, variable data, text, date, time, batch number, symbol, QR code, bar code, counter, GS1, logo etc Code:Code11, Code16k, Code39, Code 49, Code93, Code128, EAN8,EAN13, EAN14, UPCA, UPCE, INT25, ITF14, PDF417, Micro QR Code, Grid Matrix, Data Matrix, GS1 DataBar-14, GS1-EAN128, GS1-DM, GS1-QRcode, Others can be customized. Ink Type: Water-based, solvent-based, UV ink Ink Management: Automatically calculate the remaining ink and estimate print Font:Any fonts can be added Cartridge Type:12.7mm, 25.4mm Material: Aluminum Image Format:jpg, png, bmp, css, web, etc Operating System: jpg, png, bmp, css, web, etc Electrical Requirement:100 - 230 ACV, 5A, 50/60Hz, 1PH Variable Data Format: Csv, txt, xlsx, xls PC Software Format: MS EXCEL, MS Access, SQL2000, SQL2005, SQL2008 Printer Models RE 10.1 Print Height: 12.7 or 25.4mm (1 Head) RE 10.2 Print Height: 25.4 or 50.8mm (2 Head) Specifications Display:10-inch capacitive touch screen Electrical Requirement:100-230 ACV, 5A, 50/60Hz, 1PH Technology: Thermal Inkjet Technology 2.5 Operating Temperature: 5 - 45 °C and 90% air humidity, non-condensing Resolution:600 dpi, 300 dpi, 150 dpi Print Speed: Speed up to 120m/min at 300*600 dpi Density: Up to 3 levels of optical density Throw Distance:2-5mm recommended Working Environment: Temperature 0-45°C /Humidity 30-80%Rh

Operating System: Embedded Linux security operating system Display Screen: 10.1-inch colored touch screen, with a good human-computer interaction interface. Font : 5X6L, 7X6L, 7X10L, 9X8L, 9X11L, 11X11L, 12X12L, 16X16L, 24X24L, 32X32L,11X11B, 12X13B, 16X16B, 24X24B, 32X32B Communication Interface: Network interface, RS232, connection to enterprise EMS System (Various external equipment protocols can be added) Power Requirements: 220 - 240 ACV, 5A, 50/60Hz, 1PH Memory:256MB Machine Material:304 stainless steel Machine Dimension:296X296X490 (L*B*H*) Working Environment :Temperature 40-105ºF (10-40ºC) Humidity 10%-90%, Non Condensing Related Certification: CE, EAC, BIS Main Hardware: High integration of the industrial level of the new motherboard works fast and stable, which can be better to deal with the extremely harsh environment External Interface: Optical Sensor, Encoder, Signal Light Alarm, Output, Information Selection and Control,Reset Switch Support Language: Support more than 40 national languages (Chinese, English, Arabic, Danish, German, Russian, French, Finnish, Korean, Japanese, Spanish, Italian, etc). Product Details Print Head Duct:3MTR / 6MTR Nozzle Specification:150um Printing Height :5mm to 128mm Printing Distance:3mm to 30mm Printing Lines:1 to 4 Lines Printing Speed:63 m/min Counter: Up to 20 Counter Ink Colour: Black, White. Blue, Green, Yellow, Invisible Ink Type: MEK-based, Water-based, Alcohol based, Acetyl, Pigment Printing Material: Carton, Plastic, Metal, Boarding, Pipe, Stone, Cable, Glass, Electronic components, Auto parts, Industrial chemical packaging, Medical, Food Print Content: Text, Time, Date (Julian Year), Logo, Shift, SN, Dynamic Barcode/QR Code, Dynamic Serial Data, Dynamic Database.
